1928 Standard



WM2 x 19 (f), WM2 x 19 (r) (26 x 3.25") interchangeable with black enamelled rims. Rear with separate rear sprocket carrier assembly (dogged drive to wheel hub).


5" D section, unvalenced front and rear. Rear with detachable tail section


Petrol tank black with gold lined panels fitted between frame rails (flat tank). Single 2" external screw type filler. Oil tank mounted on rear frame downtube across frame with filler to offside.


4 valve 499cc with cast iron open valve cylinder head, parallel inlet valves and parallel exhaust. Forward facing parallel exhaust ports. 18mm side plug. Rockers supported on plates bolted to the cylinder head. Forward mounted ML Maglita or round ML magneto. Square based cylinder barrel and plain drive side crankcase. Total loss oiling with vertical ‘pump’ in timing cover.


Dummy belt rim front and rear, coupled to RH pedal.


Miller 6” 64E headlamp with rear switch and 34E rear lamp.


4 speed gearbox with hand change on RHS of tank. Gearbox with external kickstarter stop. Steel primary chain cover and ‘angle iron’ type rear chainguard.


Amac type 15MDY with Amac 2 lever control


Twin nickel plated short downpipes into horizontal expansion chamber mounted in front of the crankcase. Single tailpipe to rear wheel ending in detachable fishtail.


Rear carrier (at no extra charge), 7/8” non adjustable handlebars with folded type inverted levers. Rear stand. Leather fronted toolbox mounted on rear carrier on nearside of machine. Steering damper operated by wing nut through the steering head. Battery carrier (where fitted) on offside of machine to the rear of the gearbox. Leather topped pan type saddle. Closed ended ‘D’ section forks.


Rear brake lock for use when a sidecar is fitted. Footboards.
