FRAME
Built of steel tube, drop forged steel ball head, steel connecting joints and steel cradle plates.
FORKS
Spring Forks. (Regd. No 546796/09.) Perfect steering complete insulation from road vibration at any speed.
WHEELS
Specially strong steel rims for beaded tyres. 10 gauge nipples and double butted spokes. Weatherproof ball-bearing hubs. Tyres three rib beaded edge Dunlop 650 x 65 mm with two securing bolts.
BRAKES
Front rim operated by lever on right handlebar. Rear foot operated acting on exterior belt drum.
MUDGUARDS
Rear with patent combined number plate and hinged rear guard extension for rapid removal of wheel. Front with metal side extensions. Number plates on front mudguard and rear guard extension.
CARRIER
(Regd Design No. 567465.) Tubular frame. Steel plate in centre space. Metal tray with side extensions for tool boxes.
TANKS
Petrol 2 gallon, no-splash filler cap 2in diameter. Oil tank capacity 3 pints. Quick detachable filler cap. Spring-loaded pump operated by pedal.
ENGINE
Single cylinder 85 mm bore x 132 mm stroke = 750 cc. Connecting rod from drop forged steel, hardened and ground to receive roller bearings. Crankshaft supported by Ball bearings. Fly Wheels from solid steel drop forgings.
MAGNETO
High tension positive drive. Totally enclosed and weatherproof. Options available: Lucas Magneto, Lucas Mag Dynamo, BTH Magneto, ML Magneto or ML Maglita.
CARBURETTOR
Senspray, two lever control.
GEAR SYSTEM
Rudge Multi. Ratios varied infinitely between high and low limits 3 ½ to 7 to 1.
TRANSMISSION
1 inch belt.
CLUTCH
Rudge Multi 50 plate. Hand controlled by handlebar lever.
EXHAUST SYSTEM
Large expansion chamber with extension pipe to the rear.
SADDLE
Large padded seat.
STANDS
Rear, foot operated automatic spring return. Front, folding stand to front wheel supports front mudguard.
PUMP
18-inch celluloid tyre inflator with long rubber connection and ground supports.
TOOLBOX
Two armoured type fitted to rear carrier, with full set of Rudge tools.
EXTRAS
Lights.
