WM2x19 (f), WM2x19 (r). Rear, interchangeable with chrome rims. Bolt on rear sprocket.
Inverted U section, both valanced, front with bottom splash guard. Rear, two piece with detachable main section.
‘Aero’ pattern petrol tank painted black with lined panels with reserve tap. Single central CEE-ESS type filler with front fitted petrol balance pipe. Two bolt damper arm fixing.
4 valve 495cc with cast iron open valve cylinder head, parallel inlet valves and parallel exhaust.18mm side plug. BTH KD1 D4 magneto and DM3G dynamo. Oil feed to rear of cylinder.
8” front and rear, coupled with aluminium shoes.
Miller 8” headlamp with No 832 8-0-8 'Lighthouse' ammeter and 29E rear lamp. Lucas HF1441 electric horn mounted on special frame lug on rear frame tube.
4 speed gearbox with hand change on RHS of tank. Aluminium oil bath chaincase with ‘R’ on dome and separate filler on shock absorber dome.
Amal type 76/113 with Amal straight pull twist grip control.
Twin 1 3/4” low-level downpipes into barrel silencers and tail pipes with fishtails.
80MPH speedometer and ‘Revulator’. Mechanism shield, battery cover, licence holder, cast central stand with lifting handle, stop light, rear carrier, 1” handlebars. Two toolboxes fitted to either side of machine. Steering damper and handwheel operated fork shock absorber. Round tubed forks.
Upswept exhaust pipes, pillion footrests, Rudge quickly detachable and interchangeable wheel on Watsonian or Swallow sidecar. Leg shields.
